Features
- With the new generation fngerprint recognition algorithm
- Rugged, sleek and compact design
- American standard single latch for easy replacement and installation
- Independent clutch motor design under patent protection
- Idle handle design to prevent from forcible entry
- Registration data are stored even if there is power loss
- Handle,latch and strike is reversible design for all door open direction
- Capacitive sensing technology – Touch to open
- Emergency key override (concealed)
- LED indicator and inbuilt buzzer
- External terminals to draw back-up power from a 9V battery
- Low battery warning
- Normal Open mode
- Easy to program and easy to use
- Easy to install–no wiring required
- 3 user groups – Admin, Normal User and Temporary User
- Backset is 60 mm or 70mm (adjustable)
Specifcations
- Material : Zinc Alloy
- User Capacity : Admin -10 , Normal User -60 , Temporary User – 20
- Operating Temperature : -20°C – 55°C
- Power Supply : 4×AA Alkaline Battery
- Backup Unlocking Way : Mechanical Key & 9V Battery
- Door Thickness : 30-38 mm (optional) , 39-46 mm (standard) , 47-54 mm (standard) , 55-60 mm (optional)
- Dimensions : Front – 69(W)×155(L)×35(D) mm , Back – 69(W)×155(L)×25(D) mm
